Value and Performance Come with the Basics

Our RB Basics manual roller shade system provides a solid entry point for value-conscious projects. With its smooth and reliable operating clutch technology, RB Basics meets performance requirements that few others can.

Overview

The key feature of this system is its universal bracket, which makes installation quick and easy.

Product Details

Key Features

Smooth and reliable operating clutch technology
Universal bracket systems
Multiple system sizes available to suit all standard applications
Spring-loaded idle end provides easy installation
No notch fascia systems available
High-performance fabrics available including E Screen with KOOLBLACK® Technology, and Cradle to Cradle Certified™ fabrics GreenScreen® Evolve™ and GreenScreen Revive®
Backed by our Lifetime Guarantee

System Description

Mechanism: manual chain operating system has an adjustment-free ball chain (available in stainless steel, painted white steel, and painted black steel) with pulley engineered drive mechanism
Fabrics:
- Over 70 fabrics in more than 500 colors
- All fabrics are FR* rated for commercial applications
- Openness factors range from 0% to 25%
Widths: 12" to 144" (varies by fabric) †
Heights: 12" to 240" †

* Passes NFPA 701 Small Scale Flammability testing
† Larger sizes available; surcharges and warranty exclusions apply

Design Options

Fascia

Aluminum fascia (3", 4", and 5") to conceal shade mechanism from front and sides
5” fascia available on single and dual shade systems
Available in white, anodized aluminum, vanilla, bronze and black

Blockout with Side Channels

Aluminum side channels and sill channels fitted with light-blocking wool pile to prevent light leakage around edges and bottom of the shade
Ideal for room-darkening applications
Available in anodized aluminum finish or painted white, vanilla, bronze, or black

Dual Shades

Two shades operating on individual chains
Add versatility to any space by allowing two different styles of fabrics to be used on the same window (one in front of the other)
Side channel and fascia available
An unlimited number of combinations available for different shade materials

CAD / PDF Drawings

Name	Id	PDF	DWG	RVT
RB Basics Manual 3in Fascia Ceiling Mount	RBB-MAN3IN-CEILING
RB Basics Manual 4in Fascia Ceiling Mount	RBB-MAN4IN-CEILING
RB Basics Manual 5in Fascia Ceiling Mount	RBB-MANDL5IN-CEILING

Name	Id	PDF	DWG	RVT
RB Basics Manual 3in Fascia Face Mount	RBB-MAN3IN-FACE
RB Basics Manual 4in Fascia Face Mount	RBB-MAN4IN-FACE
RB Basics Manual 5in Fascia Face Mount	RBB-MANDL5IN-FACE

Installation Instructions

Download Installation Instructions

Name	Download/Play
RB Basics 3" and 4" Fascia Installation Instructions
RB Basics Dual 5" Fascia Installation Instructions
RB Basics Single 5" Fascia Installation Instructions
RB Basics Single Roller Shade Installation Instructions
Universal Cord Tensioner Installation Instructions (Inside or Outside Mount)
Universal Cord Tensioner Installation Video_Inside Mount
Universal Cord Tensioner Installation Video_Outside Mount
Universal Cord Tensioner Installation Video_Inside Mount with Angle Bracket

Sustainability

Shading Performance Guide

Find and compare the relative shading performance of Hunter Douglas Architectural fabrics for your project. Compare and contrast the key performance indicators to find the fabrics that will best fit your solar control needs.

Indoor Environmental Quality

Hunter Douglas Architectural is committed to meeting the growing demand for healthier, more sustainable products. Meeting the rigorous and comprehensive standards for low emissions of VOCs, our GREENGUARD Certified and GREENGUARD Gold Certified fabrics contribute to the overall indoor air quality and general health of a building space.

Select a PDF

Product Declarations

Hunter Douglas understands the importance of transparency to sustainable design and building. From raw material extradition through final disposal or reuse, we can provide life-cycle assessments on many of our product's environmental and health impacts.
