      RB 500+ Automated Roller Shades

      /
      Please select desired state.

      Please select desired state.

      Roller Refresh

      Our product engineers at Hunter Douglas Architectural took a fresh look at roller shades, taking the best from decades of experience to create the RB 500+ system. Features to solve tricky conditions, ensure smooth and quiet operation, and lift oversize shades with a wide selection of motorized options. Plus, a few hundred fabric choices.

      The key feature of the RB 500+ automated roller shade system is its versatility, with components to support numerous motor types and mechanisms. Perfect for commercial applications, this modular system allows installation in a wide range of shade sizes and positions.

      Product Details

      Key Features

      • Select RB 500+ Automated Roller Shade systems now UL Certified
      • Standard Duty and Heavy Duty brackets and clutches designed to fit seamlessly together, creating a sleek profile
      • Redesigned dual bracket allows for both automated and manual shades on one system
      • High-performance fabrics available including E Screen with KOOLBLACK® Technology, and Cradle to Cradle Certified™ fabrics GreenScreen Revive® and GreenScreen® Evolve™
      • Modular operating system accommodates numerous automated applications
      • Universal spring-loaded end plug mounts shades securely and provides for smooth and easy installation
      • Counter balance weight system provides for ease of lifting roller shades over large expanses.
      • Backed by our Lifetime Guarantee

      System Description

      • Mechanism: automation
      • Fabrics:
        • Over 70 fabrics in more than 500 colors
        • All fabrics are FR rated for commercial applications
        • Openness factors range from 0% to 25%
      • Widths:
        • 22"-170" (Automated, varies by fabric)
        • Up to 360" (Coupled Systems*)
      • Heights: 12" to 240" (varies by fabric*)



      * Can be exceeded with engineering approval



      Design Options


      • Motorization With Switch and Remote Control
        • Standard Motor with Centralized Group Control
        • AC motors raise and lower shades via a switch or remote control
      • Automation With Intelligent Control
        • Intelligent Wireless AC and DC Motors operate via radio frequency (RF) communication and can include wall switches, hand-held remotes, smartphones/tablets, or third-party control devices
        • Intelligent Wired AC and DC Motors offer a virtually unlimited number of timers, control input devices, and the highest level of third-party integration available
        • Battery operation available
      • Fascia, Fascia With Top and Back Cover
        • Aluminum fascia (standard 3" or 4") with top or back cover (standard 3"or 4") to conceal shade mechanism from front, sides, and top/back
        • Widths from 12" to 192"; heights from 12" to 240"
        • Available in anodized aluminum finish, white, vanilla, bronze, or black
        • 7" fascia available for dual shade systems only
      • Blockout With Side Channels
        • Aluminum side channels, sill channels, and RB 500 bottom bar, fitted with light-blocking wool pile to prevent light leakage around edges and bottom of shade
        • Ideal for room-darkening and A/V applications
        • Available in anodized aluminum finish or painted white, vanilla, bronze, or black
      • Reverse Roll
        • Fabric mounted to descend from the interior (rather than window-facing) side, concealing the roll and creating a more finished appearance
      • Oversized Shades
        • Special accommodations for oversized window applications available
      • Dual Shades
        • Add versatility to any space by allowing two different styles of fabrics to be used on the same window (one in front of the other)
        • An unlimited number of combinations available for different shade materials

      NOTE: Color and fabric images are for illustration only. For accurate specification, please request product samples.
      Click on fabric to view colorways and specifications.
      The color of a fabric and the openness of its weave play a significant role in determining occupants' views to the outside. Check out our View Through Simulation Tool to find the ideal combination for your next project.

      Filter Swatches by Openness and/or Attribute

      0%

      <1%

      1-2%

      3-5%

      6%+

      Acoustical

      Cradle to Cradle Certified ™

      EPD / HDP

      High-Performance

      PVC-Free

      0% Openness Factor

      Apollo

      Flocke®

      GlacierScreen+ RD 0%

      Morocco

      SheerWeave® 7000

      SheerWeave® 7100

      SheerWeave® 7400

      SheerWeave® 7500

      0% Openness Factor

      Sparta Twilight™ 0%

      <1% Openness Factor

      E Screen™ 0.5%

      1% Openness Factor

      E Screen Deco™ 1%

      E Screen™ 7501

      E Screen™ 7701 with KOOLBLACK® Technology

      GlacierScreen+ Basketweave 1%

      GlacierScreen+ Twill 1%

      GreenScreen Revive® 1%

      LV Classics 1%

      M Screen™ 8501

      1% Openness Factor

      SheerWeave® 2500

      SheerWeave® 2701

      SheerWeave® 4800

      SheerWeave® 4901

      SheerWeave® Infinity2™ 1%

      T Screen™ 1%

      T Screen™ 9701 with KOOLBLACK® Technology 1%

      T Screen™ Deco 1%

      1% Openness Factor

      Vizela™

      3% Openness Factor

      E Screen Deco™ 3%

      E Screen™ 7503

      E Screen™ 7703 with KOOLBLACK® Technology

      GlacierScreen+ Basketweave 3%

      GlacierScreen+ Twill 3%

      GreenScreen Evolve®

      LV Classics 3%

      M Screen Deco™ 3%

      3% Openness Factor

      M Screen™ 8503

      Natté™ 3%

      SheerWeave® 2410

      SheerWeave® 2703

      SheerWeave® 4400

      SheerWeave® 4600

      SheerWeave® 4650

      SheerWeave® 4903

      3% Openness Factor

      SheerWeave® 8000

      SheerWeave® Infinity2™ 3%

      T Screen™ 3%

      T Screen™ 9703 with KOOLBLACK® Technology 3%

      T Screen™ Deco 3%

      5% Openness Factor

      E Screen™ 7505

      E Screen™ 7705 with KOOLBLACK® Technology

      GlacierScreen+ Basketweave 5%

      GreenScreen Revive® 5%

      LV Classics 5%

      M Screen Deco™ 5%

      M Screen™ 8505

      Natté™ 5%

      5% Openness Factor

      SheerWeave® 2000

      SheerWeave® 2390

      SheerWeave® 2705

      SheerWeave® 4000

      SheerWeave® 4500

      SheerWeave® 4550

      SheerWeave® Infinity2™ 5%

      T Screen™ Deco 5%

      10% Openness Factor

      E Screen™ 7510

      GlacierScreen+ Basketweave 10%

      Natté™ 10%

      SheerWeave® 2100

      SheerWeave® 2360

      SheerWeave® 2710

      SheerWeave® 4100

      14% Openness Factor

      SheerWeave® 3000

      25% Openness Factor

      SheerWeave® 1000

      Contact a representative

      Request a sample by emailing us.

      Please select desired state.

      Please select desired state.



      Name Id PDF DWG RVT
      RB 500+ Standard Duty Auto Bracket 38 Ceiling MountRB+MOT-SDB38-CEILING
      RB 500+ Standard Duty Auto Bracket 46 Ceiling MountRB+MOT-SDB46-CEILING
      RB 500+ Standard Duty Auto Bracket 55 Ceiling MountRB+MOT-SDB55-CEILING
      RB 500+ Standard Duty Auto 3in Fascia Bracket Ceiling MountRB+MOT-3IN-CEILING
      RB 500+ Standard Duty Auto 3in Fascia Bracket Blockout Ceiling MountRB+MOT-3INBO-CEILING
      RB 500+ Heavy Duty Auto Bracket 55L Ceiling MountRB+MOT-HD55L-CEILING
      RB 500+ Heavy Duty Auto Bracket 75L Ceiling MountRB+MOT-HD75L-CEILING
      RB 500+ Heavy Duty Auto 4in Fascia Bracket Ceiling MountRB+MOT-4IN-CEILING
      RB 500+ Heavy Duty Auto 4in Fascia Bracket Blockout Ceiling MountRB+MOT-4INBO-CEILING
      RB 500+ Heavy Duty Auto Single Roller 7in UM with Fascia Ceiling MountRB+MOT-SINGLE UM-CEILING
      RB 500+ Heavy Duty Auto Dual Roller 7in UM with Fascia Ceiling MountRB+MOT-UM-CEILING
      Name Id PDF DWG RVT
      RB 500+ Standard Duty Auto Bracket 38 Face MountRB+MOT-SDB38-FACE
      RB 500+ Standard Duty Auto Bracket 46 Face MountRB+MOT-SDB46-FACE
      RB 500+ Standard Duty Auto Bracket 55 Face MountRB+MOT-SDB55-FACE
      RB 500+ Standard Duty Auto 3in Fascia Bracket Face MountRB+MOT-3IN-FACE
      RB 500+ Standard Duty Auto 3in Fascia Bracket Blockout Face MountRB+MOT-3IN-BO_FACE
      RB 500+ Heavy Duty Auto Bracket 55L Face MountRB+MOT-HD55L-FACE
      RB 500+ Heavy Duty Auto Bracket 75L Face MountRB+MOT-HD75L-FACE
      RB 500+ Heavy Duty Auto 4in Fascia Bracket Face MountRB+MOT-4IN-FACE
      RB 500+ Heavy Duty Auto 4in Facia Bracket Blockout Face MountRB+MOT-4IN_BO-FACE
      RB 500+ Heavy Duty Auto Single Roller 7in UM with Fascia Face MountRB+MOT-SINGLE UM-FACE
      RB 500+ Heavy Duty Auto Dual Roller 7in UM with Fascia Face MountRB+MOT-UM-FACE
      Name Id PDF DWG RVT
      RB 500+ Standard Duty Auto Bracket 38 Wall MountRB+MOT-SDB38-WALL
      RB 500+ Standard Duty Auto Bracket 46 Wall MountRB+MOT-SDB46-WALL
      RB 500+ Standard Duty Auto Bracket 55 Wall MountRB+MOT-SDB55-WALL
      RB 500+ Standard Duty Auto 3in Fascia Bracket Wall MountRB+MOT-3IN_WALL
      RB 500+ Standard Duty Auto 3in Fascia Bracket Blockout Wall MountRB+MOT-3IN_BO-WALL
      RB 500+ Heavy Duty Auto Bracket 55L Wall MountRB+MOT-HD55L-WALL
      RB 500+ Heavy Duty Auto Bracket 75L Wall MountRB+MOT-HD75L-WALL
      RB 500+ Heavy Duty Auto 4in Fascia Bracket Wall MountRB+MOT-4IN-WALL
      RB 500+ Heavy Duty Auto 4in Fascia Bracket Blockout Wall MountRB+MOT-4IN_BO-WALL
      RB 500+ Heavy Duty Auto Single Roller 7in UM with Fascia Wall MountRB+MOT-SINGLE UM-WALL
      RB 500+ Heavy Duty Auto Dual Roller 7in UM with Fascia Wall MountRB+MOT-UM-WALL
      Name Id PDF DWG RVT
      RB 500+ Standard Duty Auto Bracket 38 Inside MountRB+MOT-SDB38-INSIDE
      RB 500+ Standard Duty Auto Bracket 46 Inside MountRB+MOT-SDB46-INSIDE
      RB 500+ Standard Duty Auto Bracket 55 Inside MountRB+MOT-SDB55-INSIDE
      RB 500+ Standard Duty Auto 3in Fascia Bracket Inside MountRB+MOT-3IN_INSIDE
      RB 500+ Standard Duty Auto 3in Fascia Bracket Blockout Inside MountRB+MOT-3IN_BO-INSIDE
      RB 500+ Heavy Duty Auto Bracket 55L Inside MountRB+MOT-HD55L-INSIDE
      RB 500+ Heavy Duty Auto Bracket 75L Inside MountRB+MOT-HD75L-INSIDE
      RB 500+ Heavy Duty Auto 4in Fascia Bracket Inside MountRB+MOT-4IN-INSIDE
      RB 500+ Heavy Duty Auto 4in Fascia Bracket Blockout Inside MountRB+MOT-4IN_BO-INSIDE
      Name Id PDF DWG RVT
      RB 500+ Standard Duty Auto Bracket 38 - 5.25" Surface PocketRB+MOT-SDB38-SURF_PKT
      RB 500+ Standard Duty Auto Bracket 46 - 5.25" Surface PocketRB+MOT-SDB46-SURF_PKT
      RB 500+ Standard Duty Auto Bracket 55 - 5.25" Surface PocketRB+MOT-SDB55-SURF_PKT
      RB 500+ Heavy Duty Auto Bracket 55L - 5.25" Surface PocketRB+MOT-HD55L-SURF_PKT
      RB 500+ Heavy Duty Auto Single Roller 7in UM - 9in Surface PocketRB+MOT-SINGLE UM-SURF_PKT
      RB 500+ Heavy Duty Auto Dual Roller 7in UM - 9in Surface PocketRB+MOT-UM-SURF_PKT
      RB 500+ Heavy Duty Auto Single Roller 9in UM - 9in Surface PocketRB+MOT-9UM-SURF_PKT
      RB 500+ Heavy Duty Auto Dual Roller 9in UM - 9in Surface PocketRB+MOT-9DUAL-UM-SURF_PKT
      Name Id PDF DWG RVT
      RB 500+ Standard Duty Auto Bracket 38 - 5.25in Tile PocketRB+MOT-SDB38-TILE_PKT
      RB 500+ Standard Duty Auto Bracket 46 - 5.25in Tile PocketRB+MOT-SDB46-TILE_PKT
      RB 500+ Standard Duty Auto Bracket 55 - 5.25in Tile PocketRB+MOT-SDB55-TILE_PKT
      RB 500+ Heavy Duty Auto Bracket 55L - 5.25in Tile PocketRB+MOT-HD55L-TILE_PKT
      RB 500+ Heavy Duty Auto Single Roller 7in UM - 9in Tile Pocket RB+MOT-SINGLE UM-TILE_PKT
      RB 500+ Heavy Duty Auto Dual Roller 7in UM - 9in Tile PocketRB+MOT-UM-TILE_PKT
      RB 500+ Heavy Duty Auto Single Roller 9in Um - 9in Tile PocketRB+MOT-9UM-TILE_PKT
      RB 500+ Heavy Duty Auto Dual Roller 9in UM - 9in Tile PocketRB+MOT-9DUAL-UM-TILE_PKT
      Name Id PDF DWG RVT
      RB 500+ Standard Duty Auto Bracket 38 Gypsum Wallboard PocketRB+MOT-SDB38-GWB_PKT
      RB 500+ Standard Duty Auto Bracket 46 Gypsum Wallboard PocketRB+MOT-SDB46-GWB_PKT
      RB 500+ Standard Duty Auto Bracket 55 Gypsum Wallboard PocketRB+MOT-SDB55-GWB_PKT
      RB 500+ Heavy Duty Auto Bracket 55L Gypsum Wallboard PocketRB+MOT-HD55L-GWB_PKT
      RB 500+ Heavy Duty Auto Bracket 75L Gypsum Wallboard PocketRB+MOT-HD75L-GWB_PKT
      RB 500+ Heavy Duty Auto Single Roller 7in UM Gypsum Wallboard PocketRB+MOT-SINGLE UM-GWB_PKT
      RB 500+ Heavy Duty Auto Dual Roller 7in UM Gypsum Wallboard PocketRB+MOT-UM-GWB_PKT
      RB 500+ Heavy Duty Auto Single 9in UM Gypsum Wallboard PocketRB+MOT-9UM-GWB_PKT
      RB 500+ Heavy Duty Auto Dual Roller 9in UM Gypsum Wallboard PocketRB+MOT-9DUAL-UM-GWB_PKT

      Download Installation Instructions

      Name Download/Play
      RB 500 Motorized Coupled Roller Shades Installation Instructions
      RB 500 and RB 500+ Side Channel Installation Instructions
      RB 500+ Automated Heavy Duty Roller Shade_Inside Mount
      RB 500+ Automated Roller Shade with 4” Fascia_Outside Mount
      RB 500+ Automated Roller Shade with 4” Fascia_Inside Mount
      RB 500+ Dual Automated Roller Shade with 7" Fascia_Outside Mount

      Indoor Environmental Quality

      Hunter Douglas Architectural is committed to meeting the growing demand for healthier, more sustainable products. Meeting the rigorous and comprehensive standards for low emissions of VOCs, our GREENGUARD Certified and GREENGUARD Gold Certified fabrics contribute to the overall indoor air quality and general health of a building space.

      Select a PDF

      Product Declarations

      Hunter Douglas understands the importance of transparency to sustainable design and building. From raw material extradition through final disposal or reuse, we can provide life-cycle assessments on many of our product's environmental and health impacts.

      Select a PDF

      Name Download
      Standard Motor to SwitchPDF
      Intelligent Motor to Wireless RTS SwitchPDF
      Intelligent Motor to Wired SDN SwitchPDF
      Name Download
      2 Standard Motor to 1 DP/DT SwitchPDF
      Individual Group Control (IGC) 4N1 Motor Controller Installation and Operating InstructionsPDF
      Intelligent Motor to Wireless RTS SwitchPDF
      Intelligent Motor to Wired SDN SwitchPDF
      Name Download
      Individual Group Control (IGC) 4N1 Motor Controller Third Party IntegrationPDF
      Universal RTS Interface Specification SheetPDF
      TaHoma® RTS/Zigbee Smartphone and Tablet InterfacePDF
      Somfy Connect™ UAI Plus Info SheetPDF
      Somfy® SDN 2.0 with animeo® IP Information SheetPDF
      Name Download
      Fast Connector Info SheetPDF
      Alternative Control Options for Standard MotorsPDF
      Standard Motor to SwitchPDF
      Individual Group Control (IGC) 4n1 Controller Info SheetPDF
      Individual Group Control (IGC) 4n1 Connection ConfigurationPDF
      Individual Group Control (IGC) 4N1 Motor Controller Dual Shade ApplicationPDF
      Individual Group Control (IGC) 4N1 Motor Controller Installation and Operating InstructionsPDF
      Individual Group Control (IGC) 4N1 Motor Controller Technical SheetPDF
      Individual Group Control (IGC) 4N1 Motor Controller Solar Shade ApplicationPDF
      Individual Group Control (IGC) 4N1 Multi Motor Controller Solar Shade ApplicationPDF
      Individual Group Control (IGC) 4N1 Motor Controller Two Room One IGC ApplicationPDF
      Individual Group Control (IGC) 4N1 Motor Controller Third Party IntegrationPDF
      Individual Group Control (IGC) 4N1 Motor Controller RTS Receiver ApplicationPDF
      DecoFlex Dry Contact Keypad Info SheetPDF
      Name Download
      Sonesse® Ultra 50 RA 506A2PDF
      Sonesse® 50 RA 506S2PDF
      Sonesse® 50 RA 510S2PDF
      LT50 RA 525A2PDF
      50 Series Motor Limit SettingPDF
      Sonesse® 40 WT (404S2, 406A2, 409R2)PDF
      40 Series Motor Limit SettingPDF
      Name Download
      Fast Connector Info SheetPDF
      Somfy RTS Information SheetPDF
      Intelligent Motor to Wireless RTS SwitchPDF
      Telis 1 Chronis RTS Hand-Held RemotePDF
      Situo® RTS Hand-Held RemotePDF
      Situo® RTS Specification SheetPDF
      DecoFlex Wirefree Keypad InstructionsPDF
      RTS RepeaterPDF
      DecoFlex Wirefree RTS Table Top AccessoryPDF
      DecoFlex Wirefree RTS Wall SwitchPDF
      Telis RTS Hand-Held RemotePDF
      Telis 1 Chronis RTS InstructionsPDF
      Telis 16 Hand-Held RemotePDF
      Telis 16 RTS Hand-Held Remote Specification SheetPDF
      TaHoma® RTS/Zigbee Smartphone and Tablet InterfacePDF
      TaHoma® RTS/Zigbee Smartphone and Tablet Interface SpecificationsPDF
      Universal RTS Interface Operating InstructionsPDF
      Universal RTS Interface Specification SheetPDF
      Universal RTS InterfacePDF
      Smoove® 1 RTS Wall SwitchPDF
      Smoove® 4 RTS Wall SwitchPDF
      Smoove® RTS Wall SwitchPDF
      Soliris RTS Installation InstructionsPDF
      Soliris RTS Sun and Wind SensorPDF
      24v DC RTS Motor Connection Configuration with Plug-in Power SupplyPDF
      24V DC RTS Motor Connection Configurations with Power Distribution EnclosurePDF
      Name Download
      Sonesse® Ultra 50 RTS 506A2PDF
      Sonesse® 50 RTS 506S2PDF
      Sonesse® 50 RTS 510S2PDF
      LT50 Altus RTS 525A2PDF
      Sonesse® 40 RTS (404S2, 406A2, 409R)PDF
      Sonesse® 40 Wirefree RTS Li-ionPDF
      Roll Up 28 Wirefree RTSPDF
      Sonesse® 28 WIREFREE RTSPDF
      Sonesse® 30 RTSPDF
      Sonesse® 30 Wirefree RTS Li-ionPDF
      Sonesse® Ultra 30 Wirefree RTS Li-ionPDF
      Sonesse ® Ultra 50 DC RTSPDF
      Name Download
      Fast Connector Info SheetPDF
      Somfy® SDN 2.0 Information SheetPDF
      Intelligent Motor to Wired SDN SwitchPDF
      Bus Power Supply Somfy Digital Network OverviewPDF
      Data Hub Specification SheetPDF
      Data Panel Specification SheetPDF
      ExtenderPDF
      Power Panel for SDNPDF
      Somfy Connect™ UAI Plus Info SheetPDF
      Somfy Connect BMS InterfacePDF
      Somfy Connect™ LTI Info SheetPDF
      Name Download
      Sonesse® Ultra 50 RS485 506A2PDF
      Sonesse® 50 RS485 506S2PDF
      LT50 RS485 515S2PDF
      Sonesse® 30 RS485PDF
      Sonesse® Ultra 50 DC RS485PDF
      Name Download
      Somfy® SDN 2.0 with animeo® IP Information SheetPDF
      animeo IP Sub ControllerPDF
      animeo IP Building ControllerPDF
      Compact Sensor StationPDF
      Sensor StationPDF
      Back To Top
      x
